SKU: 3094806

Hörmann series 20 / 30 industrial sectional door | 142 mm | Torsion spring with plastic tube and tension cone

Name: Hörmann series 20 / 30 industrial sectional door | 142 mm | Torsion spring with plastic tube and tension cone
Brand: Hörmann
SKU: 3094806
Price: 480.0 EUR
Availability: InStock

€480,00

Tax included Shipping calculated at checkout.

Hörmann torsion springs series 40/50 for industrial sectional doors

Genuine Hörmann torsion springs with plastic tube and tension spring for industrial sectional doors of the 40/50 series. All relevant R and L variants in one article – safe spring replacement with support from Tormeister 24.

⚠️ Important safety notice – always replace both springs

Always replace both springs!
The springs are calculated based on a defined number of load cycles. If one spring breaks on a gate, the other spring is also close to its calculated breaking point and could break suddenly at any time. For maximum workplace safety and personal protection , replacement in pairs is mandatory .

📦 Variants of the 40/50 series – R80–R96 / L80–L96 series

These variants are frequently used in small to medium-sized Hörmann industrial and garage doors of the 40/50 series.

R80

L80

R81

L81

R82

L82

R83

L83

R84

L84

R85

L85

R86

L86

R87

L87

R88

L88

R89

L89

R90

L90

R91

L91

R92

L92

R93

L93

R94

L94

R95

L95

R96

L96

Note: L-variants are left-hand wound springs (for one side of the shaft), R-variants are right-hand wound. The exact combination can be found in the Hörmann spring diagram or on the nameplate.

📦 Variants of the 40/50 series – R228–R329 & 510–526

These spring series are typically used on larger industrial sectional doors with a higher door leaf weight.

R228

R229

R230

R231

R232

L232

R310

L310

R311

R312

R313

R314

R315

R316

R317

L317

R318

R319

R320

R321

R322

R323

R324

R325

R326

L326

R327

R328

R329

L329

R510

L510

R511

R512

R513

R514

R515

R516

R517

R518

R519

R520

R521

R522

R523

R524

R525

R526

L526

Tip: For accurate identification, simply send us a photo of the gate's nameplate or the aluminum tag on the spring . Tormeister 24 will check the correct R/L combination for your system.

🔧 Technical Notes & Application

Suitable for Hörmann industrial sectional doors of the 40 and 50 series.
With plastic tube and tension spring depending on the version
Designed for defined load cycles according to Hörmann spring calculations
It balances the weight of the gate leaf and relieves the drive mechanism.
In case of spring breakage: Immediately take the gate out of service and replace the springs in pairs.

Workplace safety: Replacing torsion springs is one of the most dangerous jobs on a gate. Tensioning work may only be carried out by trained technicians using suitable tensioning rods, personal protective equipment (PPE), and in a secured work area. Tormeister 24 supports you with selection, delivery, and, upon request, professional installation.

🔗 Relevant categories & accessories

❓ FAQ – Frequently Asked Questions about Hörmann BR 40/50 Springs

How do I find the correct spring (R/L number)?

The identification number (e.g., R228, L326) is located on a small aluminum tag attached to the spring or on the gate's nameplate. If nothing is legible, send a photo to Gatekeeper 24.

Why do I always have to replace both springs?

Both springs have the same number of load cycles. If one breaks, the second is right at its breaking point – it could break spontaneously. For safety reasons, always replace them in pairs.

Is the operator allowed to replace the spring themselves?

No. Torsion springs are under high tension. Work on them should only be carried out by qualified personnel – otherwise, there is a risk of serious injury or death.

Will these springs also fit private garage doors?

The 40/50 series is primarily used in industrial and commercial applications. Please inquire separately for garage doors.

🛒 Request a quote for Hörmann torsion springs now

Are you unsure which Hörmann spring you need? Send us the type plate or a photo of the spring – Tormeister 24 will find the right solution.

Start inquiry & consultation
